Mission LX-3D MKII – Surround Speaker – Pair

Shop By Brand: Mission

LX-3D MKII

The LX MKII Series is the latest in a long line of distinguished Mission loudspeakers, joining the multi-award winning speakers from the mid-level QX Series and the flagship ZX Series. LX MKII maintains the Mission trademark ‘Inverted Driver Geometry’ design, which means the path length between the drivers is optimised. Unique at this price-point, this arrangement allows the precision-tuned crossover to yield improved transient attack and astonishing detail.

Perfected over hundreds of hours of critical listening by Mission’s lead acoustic designer, Peter Comeau, Mission LX MKII utilises trickle-down innovations from the revered ZX series. Improvements in the famous Mission DiaDrive bass unit offer superior control of the low-frequency diaphragm while a refined high-frequency performance and a re-engineered cabinet bracing system further help create a loudspeaker system that outperforms its price-class.

Continuous Innovation
From over 40 years of British Hi-Fi heritage and experience, LX MKII is a representation of Mission’s non-stop pursuit of improvement and excellence

Advanced New Driver Surrounds and Crossover
One of the critical areas highlighted by the development of Mission ZX and QX models was the use of serrations in the driver surrounds to help scatter interfering reflections from localised surfaces to the dome and cone.

LX MKII now incorporates these serrations into the driver surrounds, adding further finesse to the drive unit outputs and providing a smoother frequency response.

With minor perturbations in the driver response ironed out, the crossover for each model has been optimised to take advantage of the improved performance.

The result is that the LX MKII builds on the winning formula of the LX, both enhancing the clarity of midrange and treble detail and improving the micro-dynamics of the musical performance for an even more thrilling listener experience.

Inverted Geometry Drive Design
Mission’s classic IDG (Inverted Driver Geometry) driver format positions the high frequency below the bass / midrange driver meaning the length of path is equalised so the sound waves coincide at the listener’s head height. A proprietary principle that improves ‘time alignment’ and thus transient performance in Mission speakers

A New Start, With a New Finish
Standout new finish options follow the Mission mantra of fusing Hi-Fi heritage with contemporary design.

LX MKII is the epitome of affordable high-end audio, harnessing materials, techniques and technologies that you would only expect to find in other speakers costing many times the price.

Whatever your choice of music, LX MKII will reproduce it with outstanding accuracy, detailing and realism, embodying Mission’s traditional adage since the 1970s.

TECHNICAL SPECIFICATIONS

General description: 2-way surround speaker Enclosure type: closed-box system Transducer complement: 2-way Bass driver: 4"(100mm) composite fibre Treble driver: 25mm microfibre dome AV shield: No Sensitivity (2.83V @ 1m): 86dB Recommended amplifier power: 20-80W Peak SPL: 99dB Nominal impedance: 8Ω Compatible Minimum impedance: 4.5Ω Frequency response (+/-3dB): 105Hz ~ 20kHz Bass extension(-6dB): 90Hz Crossover frequency: 2.8kHz Cabinet Volume (in litres): 2.2L Height (on plinth): (150+8)mm Width: 160mm Depth (with terminals): 260mm Carton size: 365 x 345 x 245mm Net weight: 2.85kg/pcs
