Dynaudio S4-W80 – In-Wall Speaker – Piece

Shop By Brand: DYNAUDIO

S4-W80

Give your room the sound it deserves, with the Studio range’s biggest in-wall speaker

Just add music. Or movies, for that matter. Whatever you’re listening to, the S4-W80 in-wall speaker from Dynaudio’s Custom Architectural Studio range delivers all the accuracy and refinement of the smaller S4-W65, and turns it up a notch.

Offering a bolder, even more authoritative sound, the S4-W80 makes easy work of bigger rooms. That’s thanks to its larger 20cm mid/bass driver, which – like the rest of the Custom Studio range – is matched with Dynaudio’s iconic 28mm soft-dome tweeter for a treble that sings.

Getting custom audio into your home shouldn’t be hard, and Dynaudio’s specially designed easy-mount frames can be installed quickly and simply during any building or renovation process.

Not planning on tearing down your walls any time soon? The frames can also be retrofitted into the majority of existing wall cavities for fuss-free installation.

SPECIFICATIONS

Type

2-way in-wall

Drivers

  • 2x tweeter: 28 mm (1 in)
  • Mid/bass: 200 mm (8 in)

Frequency response (+/- 3 dB)

45 Hz–20 kHz

Impedance (nominal/minimum)

8 Ω / 5 Ω

Sensitivity (dB SPL [2.83 V/1 m] )

89ndB

Continuous power

100 W

Long term power

140 W

Tweeter level options:

-3 dB, 0 dB +3 dB

Dimensions/Depth:

  • 236.5 x 391.5mm / 99mm
  • 9 5/16 x 15 3/8in / 3 15/16in

Cut-out dimensions retro-fit

215 x 370mm 8 1/4 x 14 9/16in

Grille material

Painted steel

Grille options

Rectangular

Grille attachment

Magnetic

Grille finish

White (paintable)

Certifications

CE

Environmental

RoHS
